Steady operation voltage and good safety.
OCV: 2.8～3.2V, CCV: 2.0V. Operation voltage is changed by loads, usually 2.3～2.7V.
Wide operation temperature range(-20℃～+75℃)
Excellent shelf life(10 years), low self-discharge(1% or less per year)
| GB | IEC | Max.Dimension(mm) | Weight(g) | Nominal Voltage(V) | Cut off voltage(V) | Capacity(Ah) | Max. Operating current(mA) | Pulse current(mA) | Operating temperature(℃) | 参数下载 |
|---|---|---|---|---|---|---|---|---|---|---|
BR17335 | 2/3A | 17.0×33.5 | 14 | 30 | 2.0 | 1.9 | 200 | 500 | -20～+75 | |
BR34615 | D | 34.0×61.5 | 95 | 3.0 | 2.0 | 14.0 | 500 | 2000 | -20～+75 |
